Tektronix TDS654C Oscilloscope

Brand:Tektronix

Model:TDS654C

Type:Digital Oscilloscope

Bandwidth:400 MHz

Channels:4

Sample Rate:2 GS/s

Memory Depth:20 Mpts

Display Size:10.4 inches

Interface:Touchscreen, GUI

Connectivity:USB, Ethernet, GPIB

    The Tektronix TDS654C Oscilloscope stands out as a premier tool for engineers and researchers dealing with high-speed digital designs and complex circuitry. Equipped with a robust 6 GHz bandwidth, it ensures precise and reliable measurements. The oscilloscope boasts four channels, providing the versatility needed to handle multi-channel testing scenarios. Its sample rate of up to 20 GS/s allows for capturing fast-changing signals with unparalleled accuracy. With a waveform capture rate of 200,000 wfm/s, you can analyze transient events in real-time. The high-resolution 10.4-inch XGA TFT LCD display offers a clear and detailed view of waveforms, enhancing your ability to troubleshoot and debug effectively. The oscilloscope supports multiple trigger modes, including edge, pulse, TV, and logic, making it a versatile solution for a wide range of applications. Designed with user convenience in mind, the TDS654C comes equipped with DC, AC, and GND input coupling options, ensuring flexibility in various testing environments.
